Dimensions
440mm(L)x 380mm(W) x 277mm(D)

Weight
≤ 3 kg

Power supply voltage
AC 90 – 264 V, 47/63 Hz | DC -36 to -72 V

Power consumption
(fully configured) ≤ 80 W

Switching capacity
102.5 Gbps

Forward capacity
(IPv4/IPv6) 152.5 Mbps

Operating temperature
-10 – 65 °C

Storage temperature
-40 to 70 °C

Relative humidity
10 to 90%, non-condensing

GPON SoC  :
BCM68621

Switch SOC :
BCM88470

RAM
1GB DDR3

ROM
32 MB

PORTS
8x GPON Port
1x USB(2.0)
2x SFP Port(10G)
4x GE/SFP Combo Port

Type B Protection
Yes

Mac support
64K+

• ITU -T G.984.x compliant
• Supports up to 128 x ONTs
• Max. transmission distance 20km
• Uplink and downlink triple churning encrypted function with 128Bits
• Report illegal ONU registration ONU Terminal legitimacy certification
• DBA algorithm, the particle is 1Kbit/s
• Standard OMCI management function
• Time upgrade, real time upgrade ONU batch software upgrade, fixed
• PON port optical power detection

• Anti-ARP-spoofing
• Anti-ARP-flooding
• IP source guard
• IEEE 802.1x & AAA/Radius authentication
• Create IP, VLAN, MAC
• Port Isolation
• MAC address binding to the port and MAC address Filter

• Anti-DOS attack(such as ARP, Synflood, Smurf, ICMP attack), ARP
• Detection, worm and Msblaster worm attack
• SSHv2 Secure Shell
• SNMP v3 encrypted management
• Security IP login through Telnet

• User based MAC & ARP traffic examination
• Restrict ARP traffic of each user and force-out user with abnormal ARP traffic
• Dynamic ARP table-based binding
• IP, VLAN, MAC and Port binding

• ERRP (recover-time <50ms)
• Loopback-detection

• RSTP/MSTP (recover-time <1s)
• LACP (recover-time <10ms)

• IEEE 802.1p, CoS
• WRR, SP and FIFO queue schedule
• Limiting the uplink/downlink rate based on
  each ONU

• GPON OMCI
• Ping and Traceroute
• Port real-time, utilization and transmit/ receive statistic based on Telnet

• CLI, Console port, Telnet
• SNMPv1/v2/v3
• RMON (Remote Monitoring)1,2,3,9 groups MIB
• NTP
• NMS with Web based GUI

• Certified by MTCTE
